RC-8 Dissolution Tester

RC series of instruments are used for detecting velocity and extent of pharmic dissolution from tablet, capsule etc in prescriptive menstruum.
Applicable standards:
●National standard( Chinese codex ) /2010
●Corporate standard(Dissolution tester )Q/12XQ0187-2010

Features:
●It has eight vessels and six poles, with six vessels and six poles in front and other two vessels at back.
●The head part of the instrument can be artificially turned over smoothly and flexibly.
●The basket units and paddle units are made of imported stainless steel (SUS316L).
●The magnetism-pumped circular water current can heat the system evenly, and the bath liquid can achieve an equal temperature.
●A MPU is used in dissolution tester to automatically control the temperature, rotational speed and time, and the parameters can be preset at any time.
●It can be operated conveniently by keystroke. The measurement result is displayed by LED. The preset and real data can be displayed alternately in time.
●Automation: auto-test, auto-diagnose, auto-alarm.
●It can test by self and alarm automatically. The dissolution parameters of' Chinese codex 2010' are stored in and can be taken out at anytime.
●Time can be preset at many points. The beeper sounds automatically to any point, and then the tester automatically runs to the next one.

Specifications:
●Speed range (20~200)rpm
●Speed accuracy  ±2rpm
●Temperature range ambient to +45.0℃
●Temperature Stability ±0.3℃
●Preset timing nine points (1~999)min
●Time accuracy  ±0.5mm
●Paddle radial run-out  ±0.5mm
●Basket radial run-out  ±1.0mm
●Power 220V/50Hz/1200W or 110V/60Hz/1200W
●Dimension (960*440*480)mm3
